Single channel Ion Chromatograph

The WESTINGAREA Vantion S60 is a compact, single-channel benchtop ion chromatograph tailored for small-to-mid sized laboratories, third-party testing facilities, teaching labs and field-deployed bench testing. The S60 integrates an on-board electrolytic eluent generator, auto-range conductivity detection,

vacuum degassing with gas–liquid separation, and real-time consumable / leak / pressure monitoring. It balances analytical performance, ease of use and low maintenance cost for routine anion or cation analysis in environmental, food, and general water quality testing.

Core Technical Specifications

SKU Number 8120101
Model VSIC 60
Channels 1 (anion or cation)
Flow Range 0.001 – 12.000 mL/min
Max System Pressure 42 MPa
Eluent Generator On-board electrolytic (KOH / NaOH / LiOH / MSA), 0.1 – 100 mM, isocratic & gradient
Pump High-pressure, low-pulsation tandem piston pump — flow accuracy ≤0.1%, pulsation ≤0.5%
Detector Auto-range, temperature-controlled conductivity detector — 0 – 50,000 μS/cm; cell vol ≤0.4 μL; excellent
linearity & repeatability
Suppressor Self-regenerating electrolytic micro-membrane; very low dead volume (≈<40 μL for 4 mm columns;
≈<15 μL for 2 mm)
Degassing Vacuum degasser (~ −70 kPa); ≈90% efficiency at 1.0 mL/min
Column Oven Ambient +5 °C − 85 °C; set-point accuracy ±0.1 °C
Size & Power ~360 × 500 × 560 mm (W×D×H); ≈150 W typical; net weight ≈31 kg
